Duplex Slitter
+
  • Duplex Slitter

Duplex Slitter

Thickness range:0.14-0.45 mm Max cutting size:1200X1200 mm Min cutting size:  600X600 mm    Max cutting qty of first slitter:  6 strips

Product Details


Duplex Slitter

Thickness range

0.14-0.45 mm

Max cutting size

1200X1200 mm

Min cutting size:

600X600 mm

Max cutting qty of first slitter:

6 strips

Min cutting width of second slitter

65mm

Cutting error

±0.02mm

Straight angle error

200*200   ±0.05mm

Max cutting speed

32pcs/min

Power

6Kw

Compressed air:

0.6mpa

Weight:

6T
